RL78/G13
CHAPTER 6 TIMER
ARRA
Y UNIT
R01UH0146EJ010
0 Rev
.1.00
404
Sep 22, 201
1
Figure 6-58.
Example of Basic
Timing of Operation as Dela
y Counter
TEmn
TDRmn
TCRmn
INTTMmn
ab
0000H
a+1
b+1
FFFFH
TImn
TSmn
Remarks 1.
m:
Unit number (m = 0, 1), n:
Channel number (n = 0 to 7)
2.
TSmn:
Bit n of timer channel star
t register m (TSm)
TEmn:
Bit n of timer channel e
nable status register m (TEm)
TImn:
TImn pin input signal
TCRmn:
Timer count register mn (TCRmn)
TDRmn:
Timer data register mn (TDRmn)
422
