RL78/G13 CHAPTER 12 SERIAL ARRAY UNIT
R01UH0146EJ0100 Rev.1.00 548
Sep 22, 2011
Figure 12-6. Format of Serial Clock Select Register m (SPSm)
Address: F0126H, F0127H (SPS0), F0166H, F0167H (SPS1) After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SPSm 0 0 0 0 0 0 0 0
PRS
m13
PRS
m12
PRS
m11
PRS
m10
PRS
m03
PRS
m02
PRS
m01
PRS
m00
Section of operation clock (CKmk)
Note 1
PRS
mk3
PRS
mk2
PRS
mk1
PRS
mk0
f
CLK = 2 MHz fCLK = 5 MHz fCLK = 10 MHz fCLK = 20 MHz fCLK = 32 MHz
0 0 0 0 fCLK 2 MHz 5 MHz 10 MHz 20 MHz 32 MHz
0 0 0 1 fCLK/2 1 MHz 2.5 MHz 5 MHz 10 MHz 16 MHz
0 0 1 0 fCLK/2
2
500 kHz 1.25 MHz 2.5 MHz 5 MHz 8 MHz
0 0 1 1 fCLK/2
3
250 kHz 625 kHz 1.25 MHz 2.5 MHz 4 MHz
0 1 0 0 fCLK/2
4
125 kHz 313 kHz 625 kHz 1.25 MHz 2 MHz
0 1 0 1 fCLK/2
5
62.5 kHz 156 kHz 313 kHz 625 kHz 1 MHz
0 1 1 0 fCLK/2
6
31.3 kHz 78.1 kHz 156 kHz 313 kHz 500 kHz
0 1 1 1 fCLK/2
7
15.6 kHz 39.1 kHz 78.1 kHz 156 kHz 250 kHz
1 0 0 0 fCLK/2
8
7.81 kHz 19.5 kHz 39.1 kHz 78.1 kHz 125 kHz
1 0 0 1 fCLK/2
9
3.91 kHz 9.77 kHz 19.5 kHz 39.1 kHz 62.5 kHz
1 0 1 0 fCLK/2
10
1.95 kHz 4.88 kHz 9.77 kHz 19.5 kHz 31.3 kHz
1 0 1 1 fCLK/2
11
977 Hz 2.44 kHz 4.88 kHz 9.77 kHz 15.6 kHz
1 1 0 0 fCLK/2
12
488 Hz 1.22 kHz 2.44 kHz 4.88 kHz 7.81 kHz
1 1 0 1 fCLK/2
13
244 Hz 610 Hz 1.22 kHz 2.44 kHz 3.91 kHz
1 1 1 0 fCLK/2
14
122 Hz 305 Hz 610 Hz 1.22 kHz 1.95 kHz
1 1 1 1 fCLK/2
15
61 Hz 153 kHz 305 Hz 610 Hz 977 Hz
Note When changing the clock selected for fCLK (by changing the system clock control register (CKC) value), do
so after having stopped (serial channel stop register m (STm) = 000FH) the operation of the serial array
unit (SAU).
Caution Be sure to clear bits 15 to 8 to “0”.
Remarks 1. f
CLK: CPU/peripheral hardware clock frequency
f
SUB: Subsystem clock frequency
2. m: Unit number (m = 0, 1)
3. k = 0, 1
