RL78/G13 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0146EJ0100 Rev.1.00 684

Sep 22, 2011

(3) Processing flow

Figure 12-107. Timing Chart of Address Field Transmission

D7 D6 D5 D4 D3 D2 D1 D0

R/W

D7 D6

SSmn

SEmn

SOEmn

SDRmn

SCLr output

SDAr output

SDAr input

Shift

INTIICr

TSFmn

D5 D4 D3 D2 D1 D0

ACK

Address

Shift operation

Address field transmission

SOmn bit manipulation

CKOmn

bit manipulation

Remark m: Unit number (m = 0, 1), n: Channel number (n = 0 to 3), r: IIC number (r = 00, 01, 10, 11, 20, 21,

30, 31), mn = 00 to 03, 10 to 13
