Renishaw ATOM User Manual

55
www.renishaw.com
14.5
25
4.5 × 45°
2
6
10
25
7.7 9.5
4
4.6
5.6
5.6
15.75
12.5
17
2 mounting holes M3 through
CAL pad
CAL pad
2 mounting pillars
JST output connector
2
6.25
FPC input connector
1
4
Pin 1
Pin 1
Component area
Component area
Component area
2
10-way JST, GH crimp connector. 1.25mm pitch. Suitable for cable size 26 to 30 AWG. 3m JST to 15-way D-type cable A-9412-1001.
1
Care must be taken not to damage the FPC connector when tting / removing the cable.
FPC connector
1
FPC cable
ACi interface
FPC variant installation drawing
Dimensions and tolerances in mm
