10
NOTE: For stylus recommendations, refer to the Styli and accessories technical specication
(Renishaw part no. H-1000-3200).
Note 1 Performance specication is tested at a standard test velocity of 480 mm/min (18.9 in/min) with a 35 mm stylus. Signicantly
higher velocity is possible depending on application requirements.
Note 2 Trigger force, which is critical in some applications, is the force exerted on the component by the stylus when the probe
triggers. The maximum force applied will occur after the trigger point (overtravel). The force value depends on related
variables including measuring speed and machine deceleration.
Note 3 These are the factory settings; manual adjustment of the LP2 / LP2DD is possible, but the LP2H / LP2HDD is not adjustable.
Stylus overtravel limits LP2 LP2DD LP2H LP2HDD
±X / ±Y 14.87 mm
(0.55 in)
±12.5°
19.06 mm
(0.73 in)
±15°
14.87 mm
(0.55 in)
±12.5°
19.06 mm
(0.73 in)
±15°
Z 6.5 mm (0.26 in)
4.5 mm (0.18 in) when fitted with a swarf
deflector
5.0 mm (0.20 in)
4.5 mm (0.18 in) when fitted with a swarf
deflector
Mounting M16 thread, for LPE extension bars and adaptors.
Sealing IPX8, BS EN 60529:1992+A2:2013
(IEC 60529:1989+A1:1999+A2:2013)
Storage temperature −25 °C to +70 °C (−13 °F to +158 °F)
Operating temperature +5 °C to +55 °C (+41 °F to +131 °F)
Specication
