9Specication
Variants LP2 / LP2DD LP2H / LP2HDD
Principal application Workpiece inspection and job set-up on all sizes of lathes, machining centres and
CNC grinders.
Transmission type Hard-wired, or in conjunction with optical or radio transceiver modules.
Compatible
interfaces
Hard-wired
Optical
Radio
HSI, HSI-C, MI 8-4, FS1i or FS2i
OMI-2 / OMI-2T / OMI-2H / OSI or OSI-D with OMM-2 or OMM-2C
RMI-Q
Recommended styli 50 mm (1.97 in) to 100 mm (3.94 in)
Stylus material depends on application.
50 mm (1.97 in) to 150 mm (5.91 in)
Stylus material depends on application.
Weight 65 g (2.29 oz)
Sense directions ±X, ±Y, +Z
Unidirectional repeatability 1.00 µm (40 µin) 2s (see note 1) 2.00 µm (80 µin) 2s (see note 1)
Stylus trigger force
(see notes 2 and 3)
XY low force
XY high force
+Z direction
0.50 N, 51 gf (1.80 ozf)
0.90 N, 92 gf (3.24 ozf)
5.85 N, 597 gf (21.04 ozf)
2.00 N, 204 gf (7.19 ozf)
4.00 N, 408 gf (14.39 ozf)
30.00 N, 3059 gf (107.91 ozf)
