33
Parts list
Type Part number Description
LP2 A-2063-6098 LP2 probe complete with two C spanners and TK1 tool kit.
LP2DD A-2063-8020 LP2DD probe complete with two C spanners and probe head
tool kit.
LP2H A-2064-0002 LP2H probe complete with two C spanners and TK1 tool kit.
LP2HDD A-2064-0032 LP2HDD probe complete with two C spanners and probe head
tool kit.
MA2 holder A-2063-7868 MA2 probe holder, complete with holding screws.
Adaptor M-2063-7865 Shank adaptor for MA2 probe holder, complete with holding
screws.
Cable A-1016-6451 Cable assembly for MA2 probe holder.
Service kit A-2063-7542 LP2 service kit comprises: front cover, eyelid seal, spring and
O-rings.
Deector M-2063-8003 Swarf deector, Ø28mm, protects probe from hot swarf.
Diaphragm kit A-2063-8030 Outer diaphragm and O-ring replacement kit.
Conversion kit A-2063-8023 The kit converts LP2 and LP2H probes to the DD standard,
comprising: front ring, outer diaphragm, O-ring, two C spanners.
PS3-1C A-5000-3709 Ceramic stylus 50mm long with Ø6mm ball.
PS2-41 A-5000-6403 Square tool setting stylus.
Protection M-5000-7582 Stylus adaptor with weak link collision protection for straight
steel styli.
Protection M-5000-7587 Screw with weak link collision protection for straight steel styli.
Protection M-5000-7588 Screw with weak link collision protection for swivel adaptor.
TK1 A-2053-7531 Probe head tool kit.
