6.3
Parts list
NC4 units with 90° connector kits, supplied with NC4+ Blue unit:
• Ø6.0 mm (0.24 in) × 5.0 m (16.40ft) air tube
• Ø4.0 mm (0.16 in) × 5.0 m (16.40 ft) air tube
• Ø6.0 mm (0.24 in) × 20.0 m (65.61 ft) air tube
• Ø6.0 mm (0.24 in) × 12.5 m (41.01 ft) cable with 90° connector
• Air lter/regulator
• Ø6.0mm (0.24 in) to Ø4.0 mm (0.16 in) pneumatic tting
• Ø4.0 mm (0.16 in) to Ø4.0 mm (0.16 in) pneumatic tting
• blanking cap × 3
• 4.0 m (13.12 ft) length GP9 steel braided conduit
• 4.0 m (13.12 ft) length × Ø4.0 mm (0.16 in) spring conduit
• 4.0 m (13.12 ft) length × Ø6.0 mm (0.24 in) spring conduit
• NCi-6 interface
• pin spanner
• hexagonal wrenches (2 mm, 2.5 mm and 3 mm)
• bootlace ferrule (× 12)
• conduit clamp (× 2)
• cleaning swab (× 2)
• cleaning tool
• orientation tool
• mounting and adjuster plate
• laser warning sign
• quick-start guide.
Item Part number Description
NC4+ Blue F115C
90°assembly
A-6435-3030 F115+ assembly and cable with 90° connector.
NC4+ Blue F115C
(raised) 90°
assembly
A-6435-3130 F115+ assembly with raised columns and cable with 90°
connector.
NC4+ Blue F145C
90° assembly
A-6435-3230 F145+ assembly and cable with 90° connector.
NC4+ Blue F145C
(raised) 90°
assembly
A-6435-3330 F145+ assembly with raised columns and cable with 90°
connector.
