NC4+ Blue non-contact tool setting system installation guide
6.4
Parts list
NC4 accessories
Item Part number Description
Adjuster pack A-6270-0302 Replacement adjuster pack for xed system.
NCi-6 interface
assembly
A-6516-2000 NCi-6 interface and box with DIN rail mounting and two
terminal blocks.
Conduit (GP9) per
metre
P-HO01-0010 Conduit for NC4 systems with cable connector (GP9). Order
by the metre.
Conduit P-clip
(GP9)
P-CA71-0045 Conduit clamp for GP9 conduit.
Conduit O-clip
(GP9)
P-MA01-0041 O-clip for GP9 conduit.
Spring cover
Ø4.0mm (0.16 in)
M-6270-0248 4.0 m (13.12 ft) length to protect Ø4 mm (0.16 in) air tube.
Spring cover
Ø6.0mm (0.24 in)
M-6270-0249 4.0 m (13.12 ft) length to protect Ø6 mm (0.24 in) air tube.
Cable with
connector
assembly (straight,
no conduit)
A-6270-0480 12.5 m (41.01 ft) cable with straight connector.
Cable with
connector
assembly (90° no
conduit)
A-6270-0490 12.5 m (41.01 ft) cable with 90° connector.
Cable with
connector
assembly (straight,
with conduit)
A-6270-0485 12.5 m (41.01 ft) cable with straight connector and 4.0 m
(13.12 ft) of GP9 conduit, O-clip and P-clips (× 2).
Cable with
connector
assembly (90° with
conduit)
A-6270-0495 12.5 m (41.01 ft) cable with 90° connector and 4.0 m
(13.12ft) of GP9 conduit, O-clip and P-clips (× 2).
Conduit gland
(GP9)
A-6270-0383 Cable/conduit gland for NC4 systems with cable connector.
+40+ access panel A-6270-0340 Access panel 0.40+.
+50+ access panel A-6270-0350 Access panel 0.50+.
Ø4.0 mm (0.16 in)
tube installation kit
A-6270-0365 Ø4 mm (0.16 in) × 5.0 m (16.40 in) air tube, Ø4 mm (0.16 in)
to Ø4 mm (0.16 in) straight tting, blanking cap.
Ø6.0 mm (0.24 in)
tube installation kit
A-6270-0366 Ø6 mm (0.24 in) × 5.0 m (16.40 in) air tube, Ø6 mm (0.24 in)
to Ø6 mm (0.24 in) straight tting, blanking cap.
PU tube Ø6 mm
(0.24 in)
P-PF26-0070 Ø6 mm (0.24 in) air tube. Order by the metre.
