Reznor UBXC - Page 11

11
UBXC-UDXC-IOM (01-24) 1042980-0
Table 2. Heater Throw Distance (Model UBXC)
H*
(Feet
(Meters))
Distance* or Angle
45°F (25°C)
Rise
50°F (28°C)
Rise
Unit Size (MBTUh)
175 200 225 250 300 350 400
Feet (Meters)
16 (4.9)
X 29 (8.8) 31 (9.4) 31 (9.4) 34 (10.4) 27 (8.2) 32 (9.8) 32 (9.8)
Y 44 (13.4) 48 (14.6) 47 (14.3) 53 (16.2) 42 (12.8) 48 (14.6) 49 (14.9)
Z 134 (40.8) 147 (44.8) 157 (47.9) 189 (57.6) 133 (40.5) 159 (48.5) 159 (48.5)
Downward louver angle 28° 26° 29° 25° 31° 26° 26°
18 (5.5)
X 29 (8.8) 31 (9.4) 31 (9.4) 34 (10.4) 28 (8.5) 33 (10.1) 32 (9.8)
Y 44 (13.4) 49 (14.9) 47 (14.3) 54 (16.5) 41 (12.5) 49 (14.9) 49 (14.9)
Z 131 (39.9) 144 (43.9) 153 (46.6) 185 (56.4) 129 (39.3) 156 (47.5) 156 (47.5)
Downward louver angle 32° 29° 32° 28° 34° 29° 29°
*See Figure 1.
Table 3. Heater Throw Distance (Model UDXC)
H*
(Feet
(Meters))
Distance* or Angle
Unit Size (MBTUh)
30 45 60 75 100 125 150
Feet (Meters)
5 (1.5)
X 6 (1.8) 7 (2.1) 8 (2.4) 9 (2.7) 9 (2.7) 10 (3.0)
—
Y 14 (4.3) 16 (4.9) 18 (5.5) 20 (6.1) 20 (6.1) 22 (6.7)
Z 30 (9.1) 40 (12.2) 45 (13.8) 57 (17.4) 59 (18.0) 65 (19.9)
Downward louver angle 21° 20° 16° 14° 18° 14°
8 (2.4)
X 7 (2.1) 9 (2.7) 10 (3.0) 12 (3.7) 11 (3.4) 12 (3.7) 13 (4.0)
Y 13 (4.0) 16 (4.9) 18 (5.5) 22 (6.7) 21 (6.4) 23 (7.0) 24 (7.3)
Z 26 (7.9) 37 (11.3) 42 (12.8) 54 (16.5) 56 (17.1) 63 (19.2) 73 (22.3)
Downward louver angle 39° 34° 29° 25° 28° 24° 26°
10 (3.0)
X 6 (1.8) 9 (2.7) 10 (3.0) 12 (3.7) 12 (3.7) 13 (4.0) 14 (4.3)
Y 11 (3.4) 15 (4.6) 17 (5.2) 22 (6.7) 20 (6.1) 24 (7.3) 24 (7.3)
Z 22 (6.7) 33 (10.0) 39 (11.9) 52 (15.8) 52 (15.8) 60 (18.3) 69 (21.0)
Downward louver angle 52° 43° 37° 32° 36° 30° 32°
12 (3.7)
X
—
8 (2.4) 10 (3.0) 12 (3.7) 11 (3.4) 14 (4.3) 14 (4.3)
Y 12 (3.7) 16 (4.9) 21 (6.4) 19 (5.8) 23 (7.0) 24 (7.3)
Z 27 (8.2) 34 (10.4) 48 (14.6) 47 (14.3) 57 (17.4) 64 (19.5)
Downward louver angle 55° 46° 39° 44° 36° 39°
14 (4.3)
X
—
9 (2.7) 12 (3.7) 11 (3.4) 14 (4.3) 14 (4.3)
Y 14 (4.3) 19 (5.8) 17 (5.2) 22 (6.7) 22 (6.7)
Z 29 (8.8) 44 (13.4) 42 (12.8) 53 (16.1) 59 (18.0)
Downward louver angle 56° 46° 51° 43° 45°
16 (4.9)
X
—
11 (3.4) 10 (3.0) 13 (4.0) 13 (4.0)
Y 17 (5.2) 14 (4.3) 20 (6.1) 20 (6.1)
Z 38 (11.6) 34 (10.4) 47 (14.3) 53 (16.2)
Downward louver angle 54° 58° 50° 51°
18 (5.5)
X
—
11 (3.4) 11 (3.4)
Y 17 (5.2) 17 (5.2)
Z 40 (12.2) 44 (13.4)
Downward louver angle 57° 58°
*See Figure 1.
—Continued
