22
UBXC-UDXC-IOM (01-24) 1042980-0
INSTALLATION—CONTINUED
General Requirements for Vent Connections—Continued
Condensation Mitigation
⚠ CAUTION ⚠
Failure to pitch the vent run properly may damage the heater due to condensate running back
into the unit.
Exceeding vent pipe diameter and length requirements may result in condensate forming in the
vent pipe.
For units with long vent runs—over 50% of maximum vent length allowed—or installed in low ambient conditions
(below 50°F (10°C), it is recommended that vent pipes be fitted at the low point of the vent system with a tee, a
drip leg, and a cleanout cap to prevent any moisture in the vent pipe from entering the unit. The drip leg should
be inspected and cleaned out periodically during the heating season.
Any length of single-wall vent pipe exposed to cold air or run through an unheated area or an area with an ambient
temperature of 50°F (10°C) or less, must be insulated along its entire length with a minimum of 1/2-inch foil-faced
fiberglass, 1-1/2# density insulation.
For horizontal vent runs, the flue pipe must be pitched down toward the terminal end—1/4-inch per foot for
condensate drainage—for the entire length of the horizontal vent run.
Vent System Support Requirements
⚠ CAUTION ⚠
Do not rely on the heater to support either horizontal or vertical vent pipe.
Use non-combustible supports on vent pipe.
Support horizontal runs every 6 feet (1.8 meters).
Support vertical runs in accordance with the pipe manufacturer’s requirements.
Support single-wall pipe in accordance with accepted industry practice.
Vent System Sealing
Vent system joints depend on the type of pipe being used:
Category III pipe: follow manufacturer’s instructions for joining pipe sections—connect venter outlet or the vent
cap using secure, sealed joints that follow a procedure best suited to the style of Category III pipe being used.
Single-wall galvanized pipe (26-gauge or heavier): secure slip-fit connections using sheet metal screws or
rivets—seal all joints and seams using aluminum tape or silicone sealant.
For Category I vents: when connecting Type B double-wall pipe to single-wall pipe or to the vent collar, use an
adapter made by the Type B double-wall pipe manufacturer for that purpose and follow the Type B double-wall
pipe manufacturer’s instructions.
Double-wall Type B vent pipe: join pipe sections in accordance with the pipe manufacturer’s requirement—refer
to the illustrated instructions in Figure 8 to connect double-wall pipe to the heater collar, single-wall pipe, and vent
cap. Work quickly to assemble components before sealant dries.
