Reznor UBXC - Dimensions

13
UBXC-UDXC-IOM (01-24) 1042980-0
Dimensions
⚠ CAUTION ⚠
Standard units have a combustion air inlet grill and ARE NOT to be connected to a combustion
air inlet pipe.
Figure 2. Dimensions—Model UBXC (Refer to Table 4)
DIRECT-DRIVE BLOWER (UNIT SIZES 100–125)
BELT-DRIVE BLOWER (UNIT SIZES 150–400)
SIDE VIEW
(DIRECT-DRIVE BLOWER, UNIT SIZES 30–75)
TOP VIEW
FRONT VIEW
REAR VIEW
K
BD
C
A
S
Q
R
M
N
P
F
E
G
J
H
2-1/2
T
HANGER BAR
VENT CONNECTION
GAS CONNECTION
THERMOSTAT
CONNECTION
L
COMBUSTION
AIR INLET
ELECTRIC
SUPPLY
CONNECTION
