Ricoh 9050b - Specifications for Wireless LAN Board (Optional)

Specifications for Wireless LAN Board
(Optional)
This section describes specifications for the wireless LAN board.
Transmission spec.:
Based on IEEE 802.11a/b/g (wireless LAN)
Protocol:
TCP/IP, IPX/SPX, AppleTalk
Data transfer speed:
Auto select from the following speed:
1 Mbps, 2 Mbps, 5.5 Mbps, 6 Mbps, 9 Mbps, 11 Mbps, 12 Mbps, 18 Mbps, 24 Mbps, 36 Mbps,
48 Mbps, 54 Mbps
Frequency range:
• 2412 - 2462 MHz (1 - 11 channels)
• 5180 - 5320 MHz (36, 40, 44, 48, 52, 56, 60, and 64 channels)
Transmission mode:
• Ad hoc mode
• Infrastructure mode
• SmartDeviceMonitor and Web Image Monitor are supported.
Specifications for Wireless LAN Board (Optional)
85
4
