143
3. Connect Copy
This section explains how to make copies using two machines connected via the
Copy Connector (optional).
What is Connect Copy?
Connect Copy allows you to connect two machines together via a cable. When
you set up a copy job on one machine (the main machine), data is transferred to
the other (the sub-machine) so copies can be made on both simultaneously.
❖ High-speed copying for greater productivity
Large volume copy runs can be completed in shorter time. For instance, when
two 80 copies/minute machines are connected together, a speed of 160 copies/
minute can be achieved (paper size of A4K, 8
1
/
2
" × 11"K).
❖ Reducing time loss
Even if one machine stops due to a paper jam, or runs out of toner or paper,
the other machine can automatically take over and finish the job.
Note
❒ Type 3 machines can be connected with the other Type 3 machines only.
ANO045S
