SH-P1 Training
49
Slide 49
Overview
Paper Tray
Paper Feed System: Feed roller and friction pad
Paper Lift Mechanism: Tray arm and spring
Paper Detection: Remaining paper sensors & paper end
sensor
Paper Size Detection: Paper size switch
Tray Capacity: 550 sheets
Tray Extension: Available
By-pass Tray
Paper Feed System: Feed roller and friction pad
Paper Lift Mechanism: Cams and springs
Paper Detection: By-pass tray paper sensor
Paper Size Detection: None
Tray Capacity:100 sheets
No additional notes
