SH-P1 Training
95
Slide 95
Paper Feed Drive
 The paper feed motor [A] drives the feed roller [B] via a
timing belt, gears, and the feed clutch [C].
 The transport rollers [D] direct the paper to the main unit.
[A]
[C]
[B]
[D]
No additional notes.
