4.Replace
ment and
Adjustment
294
Left Rear Cover
1.
Open the rear
upper cov
er [A].
2.
Remove
the left rear cov
er [A]
by rotating it in t
he dir
ection of the arr
ow
.
•
Be carefu
l not to da
mage the
hooks on the insi
de of the le
ft rear cov
er when y
ou remove
or install the
left rear cov
er
.
Rear Upper Cover
1.
Remove
the following c
overs.
•
Left lower
cover (
Left
Lower Cov
er
)
•
Rear midd
le cover
(
Rear Middle
Cover
)
304
306
