4.Replace
ment and
Adjustment
438
Finisher Shift Roller Motor (M15)
1.
Remove
the finisher pap
er exit
motor bracket.
(
Finisher Pa
per Exit M
otor (M1
3)
)
2.
Remove
the finisher sh
ift roller
motor brac
ket [A].
3.
Remove
the finisher sh
ift roller
motor (M15)
[A].
Finisher T
ransport Motor (M12)
1.
Remove
the finisher fra
mes. (
Finisher
Frames
)
448
450
