5.System Maintenance
520
P 800/801
6. Turn ON the main power.
7. Enter the SP mode.
8. Execute SP5-846-051 (Backup All Addr Book).
9. Exit the SP mode, and then turn OFF the main power.
10. Remove the SD card from the SD Card Slot 2 (lower).
11. Reassemble the machine.
• If the capacity of SD card is not enough to store the local user information, an error message
is displayed.
• Carefully handle the SD card, which contains the user information. Do not take it back to your
location.
Upload
1. Turn OFF the main power.
2. Remove the controller cover. (IM 550F/600F/600SRF : Controller Cover (IM550F/600F), P 800/801:
Controller Cover)
3. Install the SD card, which has already been uploaded, into the SD Card Slot 2 (lower) [A].
IM 550F/600F/600SRF
