Ricoh LCIT RT5130 User Manual

2.Replacement and Adjustment
55
2. Pull the paper feed tray and paper feed unit toward you, and remove the inner cover [A].
3. Remove the tray 5th paper feed unit LED [B] from the bracket [A].
 When attaching the tray 5th paper feed unit LED, set the LED connector [B] to the rear
side of the bracket [A].
