Ricoh LCIT RT5130 User Manual

2.Replacement and Adjustment
33
Paper Feed
Paper Feed Units
Top Tray Paper Feed Unit
1. Remove the rear cover. (Front Door and Covers)
2. Remove the right cover.(Front Door and Covers)
3. Remove the inner cover. (Inner Covers)
4. Remove the top tray. (Top Tray (Tray 4))
5. Remove the bracket [A] ( x 4)
6. Push the slide rails [A] into the machine.
