6. Troubleshooting
Error Messages
Overview
The error messages will be displayed on the LCD of the operation panel if the machine has a problem.
These can be recovered by a customer.
Error Messages List
000
Cover Open
The front or top cover is open.
1. Close the front or top cover.
2.
Replace the interlock switches or actuator mechanism.
010 AIO Set Error (Black)
011 AIO Set Error (Magenta)
012 AIO Set Error (Cyan)
013 AIO Set Error (Yellow)
• Black AIO not set
•
Defective connection of the ID chip terminal on the black AIO
1. Install the AIO (black, magenta, cyan or yellow).
1. Reinstall or replace the AIO (black, magenta, cyan or yellow).
015
ITB (Image Transfer Belt) Unit Set Error
• ITB unit not set
•
The machine does not detect any signal from the TM sensors while the ITB contact motor
is initializing.
Install the ITB unit.
