Ricoh MP C305SPF

Technical Bulletin PAGE: 2/3
Reissued: 24-Mar-16
Model: GR-C1
Date: 19-Oct-15
No.: RD117056b
Method 2:
Replace the following parts as a set for higher durability.
#
Description
Old part
number
New part
number
Old
Q’ty
New
Q’ty
Int
Note
1
LEVER:RISE:PRESSURE:PEEN
D5732721
D5732723
1
1
X/O
Replace
as a set
2
LEVER:AUXILIARY
D5732725
-
1
3
TENSION SPRING:PAPER FEED
D5732734
D5732735
1
1
X/O
4
LEVER:RISE:BASE:PEEN
D5732710
D5732716
1
1
X/O
5
RETAINING RINGS-C:6
07270060E
07270060E
-
1
-
6
WASHER:MM7.2
H5192415
H5192415
1*
1*
-
2 items added
*Note:
 Do Method 2 if SC502 reoccurs even after doing Method 1.
 Reuse WASHER:MM7.2 [6], by removing it from LEVER:RISE:BASE:PEEN [1] and
reattaching it to the position shown below.
