3. Check that paper in the paper tray is not being used, and then pull the tray carefully out
until it stops.
4. Set the side fences to the size of the tab stock to be loaded, and then load it.
5. Attach the tab fence, and then align the end fence gently against the paper you loaded
while pressing the release button of the end fence.
6. Carefully slide the paper tray fully in.
• Replace the tab fence after use.
Attaching the postcard side fences in the three-tray wide Large Capacity Tray
When loading paper that is 100.0 to 139.2 mm (3.94 to 5.49 inches) in vertical length, attach the
postcard side fences.
The three-tray wide LCT is equipped with two types of postcard side fences: the long type and the short
type. Use the longer pair for Tray 4 and the shorter pair for Trays 3 and 5.
Changing the Paper Size
103
