76
6.1 Removing the Transfer Unit
1. Make sure that the system is turned off and the machine power cord is
disconnected from the power source.
2. Spread a drop cloth or some paper in front of the machine.
3. Open the left and right front covers.
The transfer unit is located on the right drawer.
CEZ120
4. Pull down the lever B5 and pull out the right drawer until it stops.
1
2
CEZ121
To Next Page
