SERVICE PROGRAM MODE 10 August, 2001
4-42
6
Mode Number/Name Function/[Setting]
5 Sub Scan Magnification Adjusts the sub scan magnification in ADF mode.
Use the ! key to toggle between + and - before
entering the value. See “Replacement and Adjustment
- Copy Adjustment” for details.
[–5.0 ~ +5.0 / 0.0 / 0.1 % step]
6 Skew Correction
Selects whether or not skew correction is done in ADF
mode.
0 = Off, 1 = On
006*
7 Original Buckle
Adjustment
Adjusts the amount of original buckle at the ARDF
registration roller when the ARDF feeds the rear side
of the original.
This SP is effective only when SP6-006-6 is at “1”.
Use the ! key to toggle between + and - before
entering the value. See “Replacement and Adjustment
- Copy Adjustment” for details.
[–5.0 ~ +5.0 / 0.0 / 0.1 mm/step]
ADF Input Check007
Displays the signals received from sensors and
switches of the ARDF.( ☛ 4.2.4)
ADF Output Check008
Switches on each electrical component (ARDF motor,
solenoid, etc.) of the ARDF for testing. (☛ 4.2.5)
Press # to switch on or $ to switch off.
ADF Free Run009
Performs an ARDF free run in duplex mode. Press #
to start.
1: To Start, 0: To cancel
This is a general free run controlled from the copier.
For more detailed free run modes, see the ARDF
manual.
Stamp Position Adjustment010*
Adjusts the stamp position in the sub-scan direction in
fax mode.
[–5.0 ~ +5.0 / 0 / 1 mm/step]
ADF Original Size Detection016*
Selects whether the machine determines that the
original is A4/LT, or 8K/16K when the APS sensor in
the ADF does not detect the original size.
8K/16K is not available for 115V machines.
[0 = Normal (LT for USA models, A4 for Europe/Asia
models)
1 = Reversed [A4 for USA models, LT for Europe/Asia
models]
2 = 8K/16K]
Finisher Input Check117
Displays the signals received from sensors and
switches in the finisher. ( ☛ 4.2.4)
Finisher Output Check118
Switches on each electrical component of the finisher
for testing. (☛ 4.2.5)
Press # to switch on or $ to switch off.
