Ricoh Russian-C2a - Registration Clutch

PAPER FEED 10 August, 2001
6-26
6.6.4 REGISTRATION CLUTCH
1. Remove the connector cover and the rear cover. (☛ 6.6.3)
2. Remove the duplex connector cover and lower rear cover. (☛ 6.6.3)
3. Remove the fly wheels [A] (1 screw).
4. Remove the registration clutch [B] (1 E-ring, 1 connector).
B027R712.WMF
[A]
[B]
