Ricoh Russian-C2a - Transfer Unit; Transfer Roller Unit

10 August, 2001 TRANSFER UNIT
6-15
Replacement
Adjustment
6.4 TRANSFER UNIT
6.4.1 TRANSFER ROLLER UNIT
1. Open the right cover [A].
2. Remove the transfer roller unit [B] (1 hook).
NOTE: Do not touch the transfer roller surface.
B027R401.WMF
[A]
[B]
