10 August, 2001 SERVICE PROGRAM MODE
4-59
Service
Tables
Reading
Number Bit Description
01
7 Not Used
6 Not Used
5 Not Used
4 Not Used
3 Upper Tray Paper Limit Sensor Activated Deactivated
2 Not Used
1 Not Used
3
0 Not Used
For 500-sheet Finisher
Reading
Number Bit Description
01
7 Stack Near-limit Sensor Activated Deactivated
6 Tray Upper Limit Sensor Activated Deactivated
5 Lever Sensor Activated Deactivated
4 Stack Height Sensor Activated Deactivated
3 Top Cover Sensor Closed Opened
2 Jogger HP Sensor Activated Deactivated
1 Exit Sensor Activated Deactivated
1
0 Entrance Sensor Activated Deactivated
7 Not Used
6 Not Used
5 Not Used
4 Staple Unit Lock Locked Not Locked
3 Staple Cartridge Sensor Activated Deactivated
2 Staple End Sensor Activated Deactivated
1 Staple Hammer HP Sensor Activated Deactivated
2
0 Staple Unit Cover Switch Closed Opened
