Ricoh SP 330DN Field Service Manual

5.System Maintenance
109
Menu
Description
to stop printing after the print total exceeds a certain set value. If the
print count exceeds this value, then "Replace Print Cartridge"
remains in the display. Then a new AIO cartridge must be installed.
This feature is a safety measure to prevent the used toner tank from
becoming full (there is no toner overflow detection mechanism).
1200DPI Power
Adjusts print density (density levels by increasing the number)
[42 to 106 / 74 (Default) / 1 /step]
Refill Mode
DFU
[Auto refill mode/ Pure refill mode]
Page Dot
Coverage
0%-2%
Displays the number of pages printed with coverage 0 to 2%.
3%-4%
Displays the number of pages printed with coverage 3 to 4%.
5%-7%
Displays the number of pages printed with coverage 5 to 7%.
8%-9%
Displays the number of pages printed with coverage 8 to 9%.
10%-19%
Displays the number of pages printed with coverage 10 to 19%.
20%-29%
Displays the number of pages printed with coverage 20 to 29%.
Above 30%
Displays the number of pages printed with coverage above 30%.
Power On Count
Displays the power on counter.
Sleep Recover Count
Displays the sleep recover counter.
Machine Series Number
DFU
Displays the machine series number.
Serial No
DFU
Displays the machine serial No.
Inrush Control
Sets the Inrush Control mode. When using with an external power
supply instead of a commercial power supply, set to "On".
[Off (Default)/ On]
Flicker Control
Sets the Flicker Control mode.
[Off (Default)/ On]
Scan Maintenance (Only for MF Models)
Menu
Description
Mono Compression
Sets the monochrome compression type for scanning.
MH (Default)/ MR/ MMR
Registration Adjust
ADF Main Reg.
Adjusts the ADF Scan main-scan registration.
[-2.0 to 2.0 / 0 (Default)/ 0.1 mm/step]
ADF Sub Reg.
Adjusts the ADF Scan sub-scan registration.
[-2.0 to 2.0 / 0 (Default)/ 0.1mm/step]
Flatbed Main Reg.
Adjusts the Flatbed Scan main-scan registration.

Ricoh SP 330DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Printing colors	Black, White
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Multi-Purpose tray	Yes
Total input capacity	550 sheets
Total output capacity	125 sheets
Paper tray media types	-
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Sound pressure level (printing)	- dB
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.72 W
Energy Star Typical Electricity Consumption (TEC)	0.41 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	262 mm
