Ricoh SP C262DNw User Manual

No. Name Description
2 Fusing Unit Lever Lower both the left and right levers when you print on an
envelope.
3 Fusing Unit Fuses toner to the paper.
You might have to move this unit to check for or remove jammed
paper.
4 Waste Toner Bottle Collects toner that is wasted during printing.
5 Transfer unit You need to remove this when you replace the waste toner bottle.
• For details about the messages that appear on the screen when consumables need to be replaced,
see page 151 "Error and Status Messages on the Control Panel".
Control Panel
DUE130
1
2 3 4 5 6 78
10 11
9
12
No. Name Description
1 [Wi-Fi Direct] key Pressing this key while Wi-Fi is disabled activates Wi-Fi and
reboots the machine automatically. Press this key while Wi-Fi
is enabled to activate or deactivate the Wi-Fi Direct function.
This indicator lights blue when the Wi-Fi Direct function is
active. After a long press of this key, configure the WPS
using the PIN code or in PBC mode. For details, see Setup
Guide.
Guide to Components
17

Ricoh SP C262DNw Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Display	LCD
Product color	Black, White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1300 W
Power consumption (ready)	60.7 W
Power consumption (printing)	- W
Energy Star Typical Electricity Consumption (TEC)	1.303 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.9 Mavericks
Linux operating systems supported	Red Hat Enterprise Linux WS 4.0, Red Hat Enterprise Linux WS 5.0, Red Hat Enterprise Linux WS 6.0
Other operating systems supported	IBM AIX 6.1, IBM AIX 7.1
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
Paper input type	Paper tray
Total input capacity	251 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Paper tray media types	-
Paper tray media weight	60 - 160 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
Processor family	Intel® Celeron® M

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	320 mm
