EXPLODED DRAWINGS AND PARTS LISTS
Key
No.
Part No. Description QTY. Key
No.
Part No. Description QTY.
1 6106501 Table Frame 1 25 6106525 M5X10 mm Bolt 6
2 6106502 M8X5 mm Hex Head Bolt 8 26 6106526 Compression Spring 1
3 6106503 Plug for Spring Bushing 2 27 6106527 Rivet 1
4 6106504 Spring Bushing 1 28 6106528 Stop Rod 1
5 6106505 Crossbar Spring 1 29 6106529 Lock Knob 1
6 6106506 Lock Sleeve 1 30 6106530 Right Foot Cushion 1
7 6106507 Nut 14 31 6106531 Upper Support Tube End Cap 6
8 6106508 Nut Cover 23 32 6106532 Upper Support of Leg 2
9 6106509 M8 Washer 30 33 6106533 Spring 1
10 6106510 Nut Bushing 23 34 6106534 Knob 1
11 6106511 Left Connection Bracket 1 35 6106535 Position Rod 1
12 6106512
Right Connection Bracket 1 36 6106536 Plastic Bushing 1
13 6106513 M6X4 mm Bolt 4 37 6106537 Washer 2
14 6106514 Support Tube End Cap 2 38 6106538 Lower Support of Leg 2
15 6106515 Tilted Support Tube Assembly 2 39 6106539 Pull Rod Bushing 1
16 6106516 Tightening Nut 1 40 6106540 Pull Rod 1
17 6106517 Stop Bolt of Tilted Support (M24X3
mm)
1 41 6106541 Double Joint 2
18 6106518 M6X40 mm Bolt 4 42 6106542 Wheel Assembly 2
19 6106519 Left Foot 1 43 6106543 M6X35 mm Bolt 4
20 6106520
Left Mounting Foot 1 44 6106544 Lower Support Assembly 2
21 6106521
Right Mounting Foot 1 45 6106545 Pull Rod of Crossbar 1
22 6106522 Right Foot 1 46 6106546 M8X45 mm Hex Head Bolt 1
23 6106523
Left Foot Cushion 1 47 6106547 M6 Nut 12
24 6106524
Lower Support Tube End Cap 2 48 6106548 Knob 2
49 6106549 Circlip 2
WTS2000L Tile Saw Stand Parts List
