Riello UPS Sentryum S3T User Manual

- 13 -
POWER CONNECTION INFORMATION
INPUT AC Line Connection 3PH + N + PE
Table 17
UPS
size
[kVA]
Max current [A] Terminal L1, L2, L3, N PE
Suggested wire L1, L2, L3, N, PE
(
*
)
PH + N
connection
3PH + N
connection
Max cross
section
[sqmm]
Max
Tightening
torque
[Nm]
Bolt
size
Cross
sectional area
L2, L3
[N x sqmm]
Cross
sectional area
L1, N, PE
(
**
)
[N x sqmm]
Type
10 66 22 16 3 M6 1 x 2.5 1 x 10
FG16R16-0,6/1 kV (90°C)
or FG7R (90°C)
15 102 34 35 5 M6 1 x 4 1 x 16
FG16R16-0,6/1 kV (90°C)
or FG7R (90°C)
20 120 40 35 5 M6 1 x 6 1 x 25
FG16R16-0,6/1 kV (90°C)
or FG7R (90°C)
BYPASS AC Line Connection PH + N + PE (Dual Input)
Table 18
UPS
size
[kVA]
Max
Continuous
current
[A]
Terminal L1B, N PE
Suggested wire L1B, N, PE
(
*
)
Maximum cross
section
[sqmm]
Tightening
torque
[Nm]
Bolt
size
Cross sectional
area
L1B, N, PE
(
**
)
[N x sqmm]
Type
10 48 16 3 M6 1 x 10
FG16R16-0,6/1 kV (90°C)
or FG7R (90°C)
15 24 35 5 M6 1 x 16
FG16R16-0,6/1 kV (90°C)
or FG7R (90°C)
20 32 35 5 M6 1 x 25
FG16R16-0,6/1 kV (90°C)
or FG7R (90°C)
OUTPUT AC Line Connection PH + N + PE
Table 19
UPS
size
[kVA]
Nominal
current In
[A]
Terminal L, N PE
Suggested wire L, N, PE
(
*
)
Maximum cross section
[sqmm]
Tightening torque
[Nm]
Bolt size
Cross sectional area
L, N, PE
(
**
)
[N x sqmm]
Type
10 43.5 16 3 M6 1 x 10
FG16R16-0,6/1 kV (90°C)
or FG7R (90°C)
15 65.2 35 5 M6 1 x 16
FG16R16-0,6/1 kV (90°C)
or FG7R (90°C)
20 87 35 5 M6 1 x 25
FG16R16-0,6/1 kV (90°C)
or FG7R (90°C)
Input Battery DC Line Connection BATT+, BATT-, BATT N, PE (Nominal voltage +240V, -240V)
Table 20
UPS
size
[kVA]
Rated Current [A]
Terminal
BATT +, BATT -, BATT N
PE
Suggested wire BATT +, BATT -, BATT N, PE
(
*
)
@nominal
battery
voltage
@end of
discharge
voltage
Maximum
cross section
[sqmm]
Tightening
torque
[Nm]
Bolt
size
Cross sectional area
+, -, N, PE
(
**
)
[N x sqmm]
Type
10 22 27 10 1.9 M6 1 x 6
FG16R16-0,6/1 kV (90°C)
or FG7R (90°C)
15 33 42 16 3 M6 1 x 10
FG16R16-0,6/1 kV (90°C)
or FG7R (90°C)
20 44 55 16 3 M6 1 x 16
FG16R16-0,6/1 kV (90°C)
or FG7R (90°C)
(*)
The suggested cross section refers to 90°C rated cables with an ambient temperature of 30°C. If different cables are used, or
installed at a higher ambient temperature, the cable size needs to be reviewed.
The cross sections indicated in the table refer to a maximum length of 10 metres
(**)
We recommend using at least two PE connection cables. If only one cable is used, it must have a minimum section of 10 mm².
