PREPARATIONS
READ THE "SAFETY MANUAL" BEFORE STARTING THE UPS INSTALLATION
INSTALLATION ENVIRONMENT
When choosing the site in which to install the UPS and the Battery Cabinet, the following points should be taken into consideration:
 Avoid dusty environments
 Check that the floor is level and capable of withstanding the weight of the UPS and the Battery Cabinet
 Avoid cramped environments that could impede the normal maintenance activities
 The relative humidity should not exceed 90%, non-condensing
 Avoid installing the equipment in places exposed to the direct sunlight or hot air
 This equipment is intended for use in a controlled environment, hence the temperature must be regulated within a range
between 0 and 40°C
The UPS may be operated within an ambient temperature of between 0 to 40°C. The recommended working
temperature for the UPS and batteries is between 20 to 25°C. Please note, if the battery has an average life
of 5 years at a working temperature of 20°C, the life is halved if the working temperature is increased to 30°C.
To maintain the temperature of the installation room to within the range indicated above, there must be a system for eliminating the
dissipated heat (the UPS kW / kcal/h / B.T.U./h dissipation values are shown in the table below). The methods that may be used are:
 Natural ventilation
 Forced ventilation, recommended if the outside temperature is less (e.g. 20°C) than the temperature at which the UPS or
Battery Cabinet is to be operated (e.g. 25°C)
 Air-conditioning system, recommended if the outside temperature is higher (e.g. 30°C) than the temperature at which the
UPS or Battery Cabinet is to be operated (e.g. 25°C)
AMBIENT AND DIMENSION DETAIL
Table 1
Sentryum Compact Sentryum Active Sentryum Xtend
Ambient temperature for the UPS 0 - 40°C
Recommended temperature for battery life 20 - 25°C
Range of relative Humidity 5 - 95% (without condensing)
Maximum Operating Altitude
Up to 1000m o.s.l.
(derating of 1% for each 100m between 1000 and 4000 m)
Storage Temperature
From -25°C up to 60°C (UPS)
-15, +40°C (for the batteries)
Isolation protection IP20
IP20
(IP21, IP30, IP31 are available
on request)
Colour RAL 7016 RAL 7016 RAL 7016
Ventilation Forced, front to rear Forced, front to rear
Forced, front to rear
(Air filter Door as option)
Cable input Bottom (rear) Bottom
Pollution degree PD2
Vibration 1 m/s
2
Overvoltage category / Protective class
OVC II / class I
UPS Dimension (WxDxH) [mm] 280 x 840 x 700 380 x 850 x 1025 440 x 840 x 1320
Shipping Weight without
batteries [kg]
10 kVA 56 85 123
15 kVA 58 87 125
20 kVA 60 89 127
Shipping Weight with full
battery configuration [kg]
10 kVA 159 291 432
15 kVA 161 293 434
20 kVA 163 295 436
Weight without batteries [kg]
10 kVA 48 68 98
15 kVA 50 70 100
20 kVA 52 72 102
Weight with full battery
configuration [kg]
10 kVA 151 278 412
15 kVA 153 280 414
20 kVA 155 282 416
