GENERAL INFORMATION
9
Outdoor unit data
Model 25 35 50 70
Cooling performance [A35 / A27]
(1)
Nominal capacity 2,60 3,60 5,20 7,00 kW
Nominal power input 0,80 1.11 1,61 2,16 kW
Rated frequency 47 63 61 Hz
Maximum frequency 65 85 Hz
Minimum frequency 24 25 20 Hz
Nominal current consumption 3,60 5,00 7,20 9,60 A
Max. current input 5,70 7,10 8,90 13,00 A
Minimum current consumption 1,40 1,80 3,20 A
Heating performance [A7 / A20]
(2)
Nominal capacity 3,40 4,20 6,00 8,10 kW
Nominal power input 0,91 1,13 1,61 2,18 kW
Rated frequency 64 Hz
Maximum frequency 99 103 99 Hz
Minimum frequency 24 25 20 Hz
Nominal current consumption 4,10 5,10 7,20 9,70 A
Max. current input 6,70 7,10 10,60 13,00 A
Minimum current consumption 1,40 1,80 2,30 3,20 A
Electrical characteristics
Power supply 230/1/50 V/Ph/Hz
Compressor
Compressor Rotary Type
Oil FW50S Type
Oil charge 0,32 0,27 0,35 0,52 l
Refrigerant R32 Type
Refrigerant charge 0,70 0,72 0,95 1,20 kg
Fan
Fan Axial Type
Quantity 1 n.
Nominal air flow 1900 2500 2900 m³/h
Minimum speed 300 rpm
Maximum speed 800 rpm
Maximum power input 40 50 kW
Cooling sound levels
Sound power level 60 61 63 65 dB(A)
Sound pressure level
(3)
46 51 52 dB(A)
Heating sound levels
Sound pressure level
(3)
47 52 53 dB(A)
Sound power level 61 62 64 66 dB(A)
(1) Outdoor air: 35 °C D.B., Indoor air: 27 °C D.B. / 19 ° W.B.
(2) Outdoor air: 7 °C D.B. / 6 °C W.B., Indoor air: 20 °C D.B.
(3) Free field value at 1 meter unit face, in compliance with GB / T7725-2004
1.8
Operating limits
Operating mode Temperature Min Max
Cooling
Indoor air (W.B.) °C 21 35
Outdoor air (D.B.) °C -15 46
Heating
Indoor air (D.B.) °C 10 27
Outdoor air (W.B.) °C -15 24
The values are based on the following condition:
— pipe length: 5 m
— difference in height: 0 m
— air flow: maximum
