Riello MCT 10 - Installation Procedures; UPS Storage and Installation Preparation

INSTALLATION
ALL THE OPERATIONS DESCRIBED IN THIS SECTION ARE TO BE PERFORMED EXCLUSIVELY BY
QUALIFIED STAFF.
The company declines all liability for damage caused by incorrect connections or operations not described
in this manual.
S TORING THE UPS AND THE B ATTERY B OX
The storage room must respect the following conditions:
Temperature: 0°÷40°C (32°÷104°F)
Relative humidity: max. 95%
P REPARING FOR INSTALLATION
P RELIMINARY I NFORMATION
UPS models 10 kVA 12 kVA 15 kVA 20 kVA
Rated power
10000 VA 12000 VA 15000 VA 20000 VA
Working temperature
0 ÷ 40 °C
Max. relative humidity during operation
90 % (non-condensing)
Max. height of installation
1000 m at rated power
(-1% Power for every 100 m above 1000 m)
max 4000 m
W x D x H
MCT
320 x 840 x 930 mm
MST
440 x 850 x 1320 mm
Weight (w/ batteries)
MCT
180 Kg 182 Kg 190 Kg 195 Kg
MST
305 Kg 310 Kg 315 Kg 320 Kg
Power dissipated at rated resistive load
(pf=0.9) and with battery as buffer *
0.63 kW
540 kcal/h
2150 B.T.U./h
0.75 kW
645 kcal/h
2560 B.T.U./h
0.86 kW
740 kcal/h
2940 B.T.U./h
1.15 kW
990 kcal/h
3930 B.T.U./h
Power dissipated at rated distortion load
(pf=0.7) and with battery charged *
0.49 kW
420 kcal/h
1670 B.T.U./h
0.58 kW
500 kcal/h
1980 B.T.U./h
0.67 kW
580 kcal/h
2290 B.T.U./h
0.90 kW
775 kcal/h
3070 B.T.U./h
Flow rate of fans for removing heat from
installation room **
340 mc/h 400 mc/h 460 mc/h 615 mc/h
Current leak to earth ***
< 5 mA
Isolation protection
IP20
Cable input
From bottom / on rear
* 3.97 B.T.U./h = 1 kcal/h
** To calculate the air flow rate, the following formula may be used: Q [m3/h] = 3.1 x P
diss
[Kcal/h] / (t
a
- t
e
) [°C]
P
diss
is the power expressed in Kcal/h dissipated by all the devices installed in the installation environment.
ta= ambient temperature, te=outside temperature. To take leaks into account, the value obtained should be increased by
10%.
The table shows an example of a flow rate with (t
a
- t
e
)=5°C and a rated resistive load (pf=0.9).
(Note: This formula is applicable if ta>te, only; if not the UPS installation requires an air-conditioning system).
*** The leakage current of the load is to be added to that of the UPS on the earth wire.
