Riello MCT 10 - Default Chapter; Table of Contents

C ONTENTS
OVERVIEW 5
M ULTI S ENTRY 5
MCT VIEWS 6
MST VIEWS 7
V IEW OF THE UPS C ONNECTIONS 8
V IEW OF THE C ONTROL P ANEL 9
B ATTERY B OX ( OPTIONAL ) 10
S EPARATE B YPASS I NPUT ( OPTIONAL ) 11
I NTERNAL T RANSFORMER 11
A DDITIONAL I NTERNAL B ATTERY C HARGERS 11
INSTALLATION 12
S TORING THE UPS AND THE B ATTERY B OX 12
P REPARING FOR INSTALLATION 12
P RELIMINARY I NFORMATION 12
E LECTROMAGNETIC C OMPATIBILITY 13
I NSTALLATION E NVIRONMENT 13
R EMOVING THE UPS AND THE B ATTERY B OX FROM THE P ALLET 14
P RELIMINARY C HECK OF C ONTENTS 16
I NSTALLING THE UPS AND THE B ATTERY B OX 16
S TEPS TO BE T AKEN TO G AIN A CCESS TO THE T ERMINALS OF THE UPS / B ATTERY B OX 16
E LECTRICAL C ONNECTIONS 17
W IRING DIAGRAMS FOR C ONNECTING TO THE E LECTRICAL S YSTEM 17
I NTERNAL P ROTECTIVE D EVICES OF THE UPS 20
E XTERNAL P ROTECTIVE D EVICES 21
C ROSS S ECTION OF THE C ABLES 22
C ONNECTIONS 22
C ONNECTIONS OF THE MODEL WITH SEPARATE BYPASS 23
R.E.P.O. 23
E XTERNAL S YNC 23
C ONNECTING THE R EMOTE M AINTENANCE B YPASS 24
C ONNECTING THE B ATTERY B OX TO THE UPS 26
M ULTIPLE E XPANSIONS 27
S ETTING THE R ATED B ATTERY C APACITY – S OFTWARE C ONFIGURATION 27
