Technical description of the burner
4.11 Electrical panel description
1 One switch for "burner on - off”
one switch for “1st - 2nd stage"
2 Fan motor contactor and thermal relay with reset button
(RLS 50)
3 Motor capacitor (RLS 28)
4 Flame sensor
5 LED panel
6 Control box base
7 4-pole socket
8 5-pole socket
9 6-pole socket
10 7-pole socket
11 Ignition transformer
10
7
9
1
5
6
3
4
11
4
2
10
7
8
1
6
5
11
Fig. 5
