Riello RLS 28 - Final Checks (with Burner Operating)

20148646
36
GB
Start-up, calibration and operation of the burner
6.11 Final checks (with burner operating)
Tab. M
 Open the thermostat/pressure switch TL
 Open the thermostat/pressure switch TS

The burner must stop
 Turn the knob of the gas maximum pressure switch to the
minimum end of scale position
 Turn the air pressure switch knob to the maximum end of
scale position

The burner must stop in lockout
 Turn off the burner and cut off the power
 Disconnect the minimum gas pressure switch connector

The burner must not start
 Disconnect the flame sensor

The burner must stop in lockout due to
ignition failure
ATTENTION
Make sure that the mechanical locking systems
on the various adjustment devices are fully tight-
ened.
