Riello RLS 300/E - Electrode and Ignition Pilot Adjustment

Installation
25
20036644
GB
4.8 Electrode and ignition pilot adjustment
Place the electrode and the ignition pilot observing the dimensions
in Fig. 16 and Fig. 17.
RLS 300 - 400 - 500/E model (Fig. 16)
27/32"
5/8"
Fig. 16
D11260
RLS 650 - 800/E model (Fig. 17)
5/8"
Fig. 17
D11256
