Riello RLS 300/E - Final Checks (with the Burner Working)

Start-up, calibration and operation of the burner
45
20036644
GB
5.9 Final checks (with the burner working)
 Open the control limit operation
 Open the high limit operation

The burner must stop
 Rotate the maximum gas pressure switch knob to the mini-
mum end-of-scale position
 Rotate the air pressure switch knob to the maximum end of
scale position
 Rotate the maximum oil pressure switch at the minimum of
the scale

The burner must stop in lockout
 Switch off the burner and disconnect the voltage
 Disconnect the minimum gas pressure switch
 Rotate the minimum low oil pressure switch at the maximum
of the scale

The burner must not start
 Cover the QRI flame detector

The burner must stop in lockout due to firing failure
WARNING
Make sure that the mechanical locking systems on
the different adjustment devices are fully tightened.
