Technical description of the burner
Tab. J
Cable lengths – Main line AC 230 V
–Display, BCI
– Load control (LR) X5-03
– External reset button
– Safety valve (SV)
– Load output
– Fuel valve
–Pilot valve
– Ignition transformer
– Other lines
Max. 100 m (100 pF / m)
For installation under the casing of the burner or in
the control panel max. 3 m (100 pF / m)
Max. 20 m (100 pF/m)
Max 20 m (100 pF/m)
Max 20 m (100 pF/m)
Max. 10 m (100 pF/m)
Max. 3 m (100 pF/m)
Max. 3 m (100 pF/m)
Max. 3 m (100 pF/m)
Max. 3 m (100 pF/m)
Cross-sections of
the power supply
lines
They should be sized for rated currents as per the pri-
mary external fuse and the fuse of the internal unit.
– Min. cross-section
– Fuses used inside the control box F1
(max. 6.3 AT)
0.75 mm²
6.3 AT DIN EN 60127 2 / 5
Environmental
conditions
Storage
– Climatic conditions
– Mechanical conditions
– Temperature range
–Humidity
DIN EN 60721-3-1
Class 1K3
Class 1M2
-20 ... +60 °C
< 95% RH
Transport
– Climatic conditions
– Mechanical conditions
– Temperature range
–Humidity
DIN EN 60721-3-2
Class 2K2
Class 2M2
-30 ... +60 °C
< 95% RH
Operation
– Climatic conditions
– Mechanical conditions
– Temperature range
–Humidity
DIN EN 60721-3-3
Class 3K3
Class 3M3
-20 ... +60 °C
< 95% RH
WARNING
Condensation, formation of ice and the entrance
of water are not permitted!
