Riello RS 70 E - Parameter List

47
20068428
GB
Start-up, calibration and operation of the burner
6.8.3 Parameter list
Parameter
No. ele-
ments
Unit of
measure
Modifica-
tion
Value range
Degree of
accuracy
Default
setting
Acces mode
No. Description Min. Max.
000 INTERNAL PARAMETERS
050
Start backup/restore process via RDI21... / PC TOOL
(set the parameter to 1)
Index 0 = create backup
Index 1 = perform restore
Negative values indicate errors
2 - Modification -99 2 1 0; 0 Service mode
055
Burner identification number created from the backup
on RDI21...
1 - Reading only 0 99999999 1 0 Service mode
056 ASN number created by the backup on RDI21... 8 - Reading only 0 127 1 0 Service mode
057 Software Version created by the backup on RDI21... 1 - Reading only 0x100 0xFFF9 1 0 Service mode
100 GENERAL PARAMETERS
102 Control box identification date 1 - Reading only 0 255 1 Info mode
103 Control box identification number 1 - Reading only 0 65535 1 Info mode
104 Identification number of the group of parameters set 1 - Reading only 0 255 1 30 Info mode
105 Version of the group of parameters set 1 - Reading only 0 0xFFFF 1 V 01.08 Info mode
107 Software version 1 - Reading only 0 0xFFF9 1 V 03.30 Info mode
108 Software variation 1 - Reading only 0 225 1 1 Info mode
111
ASN number to verify the ASN number created by the
backup on RDI 21…
8 - Reading only 0 127 1 0 Service mode
113 Burner identification 1 - Modification 0 99999999 1 Not defined
Info Mode with
password
Service Mode
121
Manual setting of output
Not defined = automatic operation
1 %
Modification /
zero setting
0% 100% 0.1% Not defined Info mode
123
Minimum output step position
Index 0: BACS output
Index 1: output of the external load regulator,
analogue.
Index 2: output of the external load regulator contacts.
3 % Modification 0% 100% 0.1%
0% ; 1%;
0%
Service mode
124
Beginning flame loss test (TÜV test) (define the
parameter at 1) (switch of flame loss fuel valves) A
negative value indicates an error (see code 150)
1 - Modification -6 1 1 0 Service mode
125
Frequency of main power supply
0 = 50 Hz
1 = 60 Hz
1 - Modification 0 1 1 0 Service mode
126 Brightness of display 1 % Modification 0% 100% 1% 75% Service mode
128
Fuel meter: Led pulse valence
(led pulses / volumetric flow units)
1 - Modification 0 400 0.01 0 Service mode
130
Eliminate visualisation error chronology
To eliminate the visualisation, set the parameter to 1,
then to 2
Answer 0: process successful
Answer -1: time-out of 1_2 - sequence
1 - Modification -5 2 1 0 Service mode
133
Default output for TÜV test:
TÜV test not valid when output is activated
2,000 ..... 10,000 = low flame or first / second / third
stage
1 %
Modification /
zero setting
20% 100% 0.1% Not defined Service mode
141
Remote management of control box
0 = off
1 = Modbus
2 = reserved
1 - Modification 0 2 1 0 Service mode
142
Standby time before a new attempt in event of com-
munication fault
Values set:
0 = not active
1 = .... 7200 s
1 s Modification 0s 7200s 1s 120s Service mode
143 Reserved 1 - Modification 1 8 1 1 Info mode
144 Reserved 1 s Modification 10s 60s 1s 30s Service mode
145
Peripheral address for Modbus
Values set:
1 ... 247
1 - Modification 1 247 1 1 Service mode
