If it proves difcult to t the washer (7) or screw the bolt (6)
into the bush (8) because the door is not accurately aligned,
attach a hoist of adequate lifting capacity to the door (see
the weights and dimensions table), slightly loosen the x-
ing bolts (1) and lift the door just enough to t the washer
(7) or align the hole in the door with the hole in the hinge.
Once the bolt (6) has engaged the bush, re-tighten the
door xing bolts (1).
− Fit the top door stop bracket (3) to the opposite side of
the door and x it in place with the safety bolts (2);
− t the bottom door stop bracket (5) to the opposite side
of the door and x it in place with the safety bolts (4).
2
3
4
5
1
1
1
1
1
1
1
1
9
Make sure that the safety bolts (2 and 4) are securely tight-
ened before attempting to open the door.
− Completely unscrew the main xing bolts (1) and open
the door (these bolts are captive in the door and cannot
be removed);
− remove the spare hinge assembly ‘B’ [bolt (9), bushing
(10), and washer (11)] opposite the hinged side of the
door.
9
11
10
B
