2.10 Changing the direction of door opening
9
Perform this operation before starting the boiler up for the
rst time and before opening the door.
9
If the door is not properly supported on its hinges, equip-
ment capable of supporting its entire weight must be used
to move it (see the table on page 10) and using suitable
safety equipment.
If you wish to modify the door to open to the left, i.e. with the
hinges on the left, proceed as follows:
9
Make sure that the main door xing bolts (1) are securely
tightened;
− remove the top safety bolts (2) and the door stop bracket
(3);
− remove the bottom safety bolts (4) and the door stop
bracket (5);
1
2
4
5
3
1
− insert a spanner through the slot in the side of the top
door mounting bracket and hold the bushing (8) steady;
− unscrew the top bolt (6), then remove the bushing (8)
and washer (7);
6
8
7
− t the bushing (8), bolt (6) and washer (7) to the opposite
side of the door.
1
1
1
1
1
1
1
1
