Rigol DG1022 Service Guide

RIGOL
DG1000 Service Guide
IV
Safety Notices and Symbols
Safety Notices in this Manual:
WARNING
Indicates a potentially hazardous situation which, if not avoided, will result
in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, could
result in damage to the product or loss of important data.
Safety Terms on the Product:
DANGER
It calls attention to an operation, if not correctly performed, could
result in injury or hazard immediately.
WARNING
It calls attention to an operation, if not correctly performed, could
result in
potential injury or hazard.
CAUTION
It calls attention to an operation, if not correctly performed, could
result in damage to the product or other devices connected to the
product.
Safety Symbols on the Product:
Hazardous
Voltage
Safety
Warning
Protective
Earth
Terminal
Chassis
Ground
Test
Ground

Rigol DG1022 Specifications

General

Model	DG1022
Type	Function/Arbitrary Waveform Generator
Channels	2
Maximum Frequency	20 MHz
Frequency Range	1 μHz to 20 MHz
Sample Rate	100 MSa/s
Vertical Resolution	14 bits
Waveform Types	Sine, Square, Ramp, Pulse, Noise, Arbitrary
Output Impedance	50 Ω
Modulation Types	AM, FM, PM, FSK, PWM
Sweep Modes	Linear, Logarithmic
Frequency Accuracy	±20 ppm
Frequency Resolution	1 μHz
Display	3.5 inch TFT LCD
Waveform Length	8 kpts
Arbitrary Waveform Length	8 kpts
Amplitude Accuracy	±(1% of setting + 1 mVpp)
Interfaces	USB Device, USB Host
Power Supply	100-240 V AC
