Rigol DHO1202 Quick Guide

4.2 Rear Panel Overview
1
2
3
4
7
6
5
10
8
9
Figure 4.3 Rear Panel
1 Trigger Output Connector
2 External Trigger Input Connector
3 10 MHz Reference Clock Input Connector
4 10 MHz Reference Clock Output Connector
5 HDMI Connector
6 USB DEVICE Port
7 LAN Port
8 AC Power Cord Connector
9 Fuse
10 Security Lock Hole
Product Overview
