4.4 User Interface Overview
1
2
3
4 5
6
7
8
10
11
12
13
9
Figure 4.6 User Interface
1
Waveform View 8 Result Sidebar
2 Run State Label 9 Split-screen Display
3 Horizontal Timebase Label 10 Notification Area
4 Sample Rate & Memory Depth
Label
11 Math Labels
5 Horizontal Position Label 12 Channel Labels
6 Trigger Label 13 Function Navigation Icon
7 Function Toolbar
Product Overview
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
