Rigol DHO900 Series Quick Start Guide

4
Product Overview
RIGOL introduces the brand new DHO900 series economy oscilloscope into its
oscilloscope family. With a compact size, the DHO900 series achieves a waveform
capture rate of 1,000,000 wfms/s with the UltraAcquire mode, 50 Mpts memory
depth, 12 bits resolution, and low noise.
4.1 Appearance and Dimensions
161.75 mm
265.36 mm
Figure 4.1 Front View
Product Overview
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
9

Rigol DHO900 Series Specifications

General

Vertical Resolution	12-bit
Resolution	12-bit
Input Coupling	DC, AC, GND
FFT Points	Up to 1 Mpts
Analog Channels	4
Memory Depth	50 Mpts per channel
Interfaces	USB Host, USB Device, LAN, HDMI
Optional Features	Decoders
Trigger Types	Edge, Pulse, Slope, Video, Pattern, Runt, Window, Serial
Math Functions	+, -, ×, /, FFT
Operating Temperature	0°C to +40°C
Input Impedance	1 MΩ
