Rigol DHO914S

To Next Page

To Previous Page

Click or tap the "Pass/Fail" label and a window is displayed for you to perform the

following operations.

• Click or tap Reset Stat., and then the statistics in the "Pass/Fail" label will be

reset to 0.

• Click or tap Setting, and then the PassFail setting menu is displayed.

• Click or tap Remove, and then the pass/fail function is disabled.

Pass/Fail Test

193
